Pulsar Merger Duo NXP50 3-24 Thermal and Digital Night Vision Binocular PL77455

Merger Duo NXP50 are innovative multispectral binoculars combining thermal and digital night vision imaging in a single unit and offering enhanced detection, recognition and identification capabilities. Merger Duo NXP50 acquires quality images in various wavelength spectrums (visible, near infrared and long-wave Infrared ranges) making it a truly versatile unit for observation at any time of the day under all weather conditions. Taking advantages of both technologies, Merger Duo makes it easy to find an object with thermal imaging, evaluate the terrain with digital night vision and identify clearly all the object’s smallest features and details with combined viewing modes.

Features
• Multispectral thermal and night vision device
• Extra low-light Full-HD digital night vision
• Highly sensitive 640x480 @ 17 μm / NETD 25 mK thermal sensor
• Thermal, digital and combined viewing modes
• Advanced Pulsar Image boost technology
• Classic binocular design
• Ergonomic and functional carrying case
• Clear trophy identification
• Rugged magnesium alloy housing
• Built-in photo and video recorder
• Invisible IR Illuminator for digital night vision
• High-contrast HD AMOLED displays
• IPX7 submersion waterproof rated
• Operation in extreme temperatures -25 to +50C

Model # (SKU) 77455
Thermal sensor resolution, pixels 640x480
Thermal sensor pixel pitch, μm 17
Thermal sensor NETD, mK 25
Digital sensor type CMOS
Digital sensor resolution, pixels 1920x1200
Display type AMOLED
Display resolution, pix. 1280х960
Built-in video recorder availability Yes
Format and resolution of video clip .mp4/1280х960
Format and resolution of photo files .jpg/1280х960
Type & capacity of memory card eMMC 64 Gb
USB, type USB Type-C
Wi-Fi, type 2.4/5Ghz
IR illuminator type Attachable
IR wavelength, nm 940
Battery type Dual Li-Ion internal + Pulsar APS3 external
Maximum operation time, h 7
External power supply, V 5V/9V USB Type-C
Magnification of thermal channel, x 3 - 24
Magnification in digital channel, x 2 - 16
Thermal channel objective lens, mm 50mm/F1.0
Digital channel objective lens, mm 50mm/F1.4
Field of view of thermal channel,  12.4
Field of view of digital channel,  21.7
Eye relief, mm 12
Diopter adjustment, dptr. -4/+3
Interpupillary distance, mm 63 − 74
Operating temperature,  С - 25 − +50
Level of protection IPX7
Waterproofness Yes
Dimensions (L x W x H), mm 207 x 140 x 73
Weight, kg 1.2
